Desktop 65W 4 ports POE switch Gigabit

Home / Products / IP Transmission / 1000Mbps POE Ethernet Switch / Detail

Desktop 65W 4 ports POE switch Gigabit

● 5 ports switch with 4 port PoE,1000Mbit each port ,1 Uplink

● PoE data & power transmission distance 100meters

● Maximum 15.4 watts power for each PoE port

● PoE Standard: IEEE 802.3af

● PoE Pin: 1/2+,3/6-

●Total Power:52V1.25A 65W

Description of this 4+1 Ports Full Gigabit POE Switch With External Power Supply

5 Ports Full Gigabit PoE Switch is specially designed for the application of high definition network security surveillance system. Besides, it could be applied in also Communications industrial; Transportation industrial; Multimedia Network Teaching System; Medical Monitoring Display System; Industrial Automation Control System; Banking, securities, financial information display system; Remote Network Server Monitoring; Department Store Security; Casino Security; Hospitals, Airports and banks; School Campuses and etc.

The PoE switch provides 4 Gigabit downlink PoE ports support 802.3af and 1 Port Gigabit uplink ports. The total PoE power output is up to 65 watts.

Smart Design , With anti-theft lock , Easy installation just Plug and Play, No Setting required.

Specification of this 4+1 Ports Full Gigabit POE Switch With External Power Supply

Item			Description
Power	Power Adapter Voltage		48-57V DC
	Consumption		65W
Network Connector	Network Port	POE Ethernet Port	1～4 Port : 10/100/1000Mbps
		Ethernet port	Uplink Port : 10/100/1000Mbps
	Transmission Distance		1~4Port:100Mbps:0~100m
			Uplink port:0~100m
	Transmission Medium		Cat5/5e/6 standard network cable
Network Switch	Network Standard		IEEE 802.3/802.3u, IEEE 802.3x,IEEE 802.3ab
	Switching Capacity		10Gbps
	Packet Forwarding Rate		7.44Mpps
	MAC Table		2K
Power Over Ethernet	POE Standard		IEEE 802.3af
	POE Power Supply Type		End-Span(1/2+;3/6-)
	PoE Power Consumption		af=15.4w(every port)
LED Status Indicator VLAN/Extend	POE Ethernet LED Indicator		Power: 1 red light indicates that the power normal work
			POE: 4 yellow lights indicate that the POE is power on
			Ethernet: 5 green lights indicate that the Ethernet link and act;
Environmental	Working temperature		0℃~55℃
	Relative Humidity		20~95%
	Storage temperature		-20℃~70℃
Mechanical	Dimension (L×W×H)		135 mm 89 mm 27mm
	Color		Black
	Weight		275g
Stability	MTBF		>30000h
